Main Features:

This series of products are mainly paper, plastic film, non-woven cloth or aluminum foil as substrate, by casting a compound into two layer, three layer (sandwich), widely used in food packaging, pharmaceutical packaging and other industries. Such as making a cup, a bowl of instant noodles, feed bags, medical materials, fast food box, non-woven bag. PLC man-machine interface control, machine, electricity, gas, integrated design; high precision Motou, high efficiency, high speed mixed refine screw, swift net changer, 360o second reel; can be equipped with a single extruder. Double screw extruder, multi-stage attack realize multilayer coextrusion.

SJFM-E model especially for baby crawling mat /baby game pad.


Main Technical Variables

Model

SJFM1100-2300E

Mechanical Specifications

1100-2300mm

Max.speed of coating film

50m

Suitable coating resin film

PE/PP/EVA

Suitable base material

EPE/BOPP/BOPET、(AL

Width of coating film

1000-2200mm

Thickness of coating film

0.008~0.05mm

Inaccuracy thickness of coating film

≦±5mm

Complex cooling roller

Φ350/Φ500/Φ600mm

Screw specification

L/D)Φ903310033110:33:

Main unwinding diameter

Φ800-1300mm

Diameter of auxiliary unwinding

Φ600mm

Diameter of rewinding

Φ800-1300mm
