Maximum diameter on unwinding/rewinding | 1500mm/1200mm |
Printing repeat | 82T – 409T (1T=3.175mm) |
Maximum width of material | 1010mm |
Maximum printing width | 1000mm |
Power of main motor | 7.5KW |
Power of rewinding motor | 15KW |
Voltage requirement | 380V 3PH 50Hz if different, please kindly inform us |
Total power | 150KW (including hot air 72kw) |
Machine speed | 0-150m/min |
Plate thickness | 1.7mm if different, please kindly inform us |
Plate mounting tap | 0.38mm if different, please kindly inform us |
Printing precision | ±0.12mm |
