Delaminating Rewinding machine
Delaminating Rewinding machine Delaminating Rewinding machine Delaminating Rewinding machine Delaminating Rewinding machine Delaminating Rewinding machine Delaminating Rewinding machine Delaminating Rewinding machine

Delaminating Rewinding machine

This machine is suitable for de-laminating/peeling off and rewinding the reusable PET film from the golden/silver paperboard or hologram cardboard, then rewind the paper board in roll.

Inquiry
Website

Material roll width

450~1200mm

Max. Unwinding diameter

∮1600mm

Max. Rewinding diameter

∮1600mm

Max. Rewinding diameter of film

∮600mm

Paper thickness

800~300gsm

Film thickness

12~30um

Mechanical speed

≤300m/min

De-laminating speed

≤250m/min

Power voltage

AC380V/3P/50Hz

Total power

30kw

Overall dimensions

(L×W×H)

57000×4000×2600mm

1200×2280×1400mm

1200×2580×1400mm

Weight

6500kg
