It is adopts micro-computer control for accurate flatten die cutting, material feeding, and sheeting, 3 points photocells for web-guiding and tracking. Die cutting, waste collecting and finished-material sheeting or rewinding are on one process. The machine could be used for die cut adhesive paper, dacron label and laser hologram label.
Model | 320G model |
cut speed | 20-300 strokes/min |
Max unwinding diameter | 500mm |
Max web width | 320mm |
Max die-cut width | 300mm |
Max die-cut Length | 300mm |
Position accuracy | ±0.1mm |
Total power | 3.5kw |
Power voltage | 220v±10% |
Machine weight | About 1700kg |
Overall dimension | 2.6(L)×0.95(W)×1.4(H)(m) |
