Description
Use Anilox roller to spread ink
Unwinding and rewinding are controlled by magnetic powder brake and clutch (or by automatic tension controller of Mitsubishi made in Japan)
Each printing unit adopt 360 degree for color registration
Each printing unit have one IR drier
The rubber roller can be break away automatically while parking, and running at a low speed in order to avoid ink being dry
The main motor is adopted the import stepless regulation of frequency conversion
Unwinding, web guiding, printing, IR drying and rewinding can be finished in one process, this is an ideal machine for printing factory to print cup paper
Specification
Model | RY-650-4B | RY-850-4B |
Printing color number | 4 color | 4 color |
Printing speed | 0~60m/min | 0~60m/min |
Max web width | 660mm | 860mm |
Max printing wide | 650mm | 850mm |
Max unwinding diameter
| 1400mm | 1400mm |
Max rewinding diameter | 1400mm | 1400mm |
Printing length | 175~380mm | 175~380mm 250~580mm |
Precision of color register | ±0.1mm | ±0.1mm |
Overall dimension (5 color) | 4000X1700X3800mm | 4000X1900X3800mm |
Machine weight | About 5000kg | About 6000kg |
