1. The machine is controlled by PLC which makes the feeding process more smooth and accurate. 2. Automatic bottom paper feeding and manual surface paper feeding structure, to ensure the convenient operating and stable location. 3. Flexible front positioning can avoid bottom sheet exceeding the surface sheet, and lamination between bottom and surface sheet is adjustable. 4. Suitable for the cardboard laminate with bottom cardboard (above 300gsm), or cardboard laminate with corrugated board (A.B.C
Model | FMT-1300 | FMT-1450 |
Max. sheet size | 1200x1300mm | 1300x1400mm |
Min. sheet size | 400x400mm | 400x400mm |
Laminating precision | ±1mm | ±1mm |
Face paper | 250~450gsm | 250~450gsm |
Bottom paper | A.B.C.E flute corrugated board | A.B.C.E flute corrugated board |
Total power | 7kw | 7kw |
Machine speed | 4500sheet/min | 4500sheet/min |
Overall dimension | 7470x1970x1420mm | 7470x2120x1420mm |
Weight | About 4200kg | About 5200kg |
