Main Technical Parameter:

Equipment Model

RC-420S

RC-520S

Width of Top Film

398mm

498mm

Width of Bottom Film

424mm

524mm

Vacuum

200Pa

Compressed Air

0.6Mpa

Air Consumption

0.6m3/min

Air Filling Pressure

0.2Mpa

Punching Speed

4-6p/min

Air Filling Connector

Ø16PU tube

Cooling Water

0.15Mpa

Power Supply

380V/50HZ

Total Power

12~18KW

Machine Dimension

6850*1150*2000mm

Machine Weight

2250kg

2450kg
