Features:
3" Air shaft for unwinding and rewinding
With photocells for web-guiding
Unwinding magnetic brake for tension control
Meter counting function
Main motor frequency converter for speed regulation
Big diameter heating cylinder assure the perfect contact area of film with paper
Disc blade for OPP film slitting
Parameter:
Model | JTFM400 | JTFM550 | JTFM700 |
Max feeding width | 370mm | 520mm | 670mm |
Max mechanical speed | 70m/min | ||
Heating roller diameter | ￠268mm, 570mm width | ||
Rubber roller diameter | ￠206mm, 570mm width | ||
Heating temperature | 0～130℃ | ||
Max unwinding diameter | ￠550mm | ||
Max rewinding diameter | ￠550mm | ||
Heating power | 6kw | 8kw | 10kw |
Total power | 9kw | 11kw | 13kw |
Max work pressure | 8Mpa | 8Mpa | 8Mpa |
Overall dimension | 1550×1200×1500 | 1550×1330×1500 | 1550×1480×1500 |
