Main features
1. High quality aluminum alloy casting, light weight, no rust
2. High output torque;
3. Smooth transmission and low noise;
4. Good heat dissipation performance;
5. Beautiful and durable, small size;
6. Gold bearing installation is applicable

Structural features
1. High-quality aluminum alloy casting box body, suitable for all-directional universal installation configuration;
2. Sufficient cooling bars enable the body to have excellent thermal conductivity;
3. There are 10 kinds of frame specifications from 025-150; Transmission power range from 60W to 15kW;
4. The speed ratio range is large, and each single stand has 12 kinds of deceleration ratio from 5:1 to 100:1;
5. Precision grinding hard tooth surface transmission worm, high efficiency, high output torque;
6. Smooth operation with low noise, suitable for medium and long term continuous work in harsh environment;
7. Light weight and high mechanical strength;
8. Modular DRV combination expands the transmission ratio of NMRV reducer to: i= 5-5000

Materials
1. Case: aluminum alloy (frame: 030-090). Cast iron (frame: 110-130)
2. Worm: 20Cr, carburized and quenched, tooth surface hardness 58-62HRC, keep carburized layer thickness 0.3-0.5mm after fine grinding
3. Worm gear: Wear resistant nickel bronze

Treatment
1. Shot blasting treatment is followed by special anticorrosion treatment to maintain silver and white metallic feeling and resist the corrosion of organic solvents such as gasoline and xylene;
2. After phosphating treatment, spray RAL5010 blue or RAL7035 light gray paint.
3. Cast iron casing : first paint red anti-rust paint, then spray RAL5010 blue or RAL7035 light gray paint.

Usage
Light load screw conveyor, fan, equipment line, conveyor belt, small agitator, elevator, cleaning machine, filter, control drive.
Winch, woodworking machine feeder, cargo crane, balancer, screw machine, medium agitator, heavy conveyor belt, capstan, sliding gate, hanging machine, packing machine, concrete mixer, driving device, milling machine, gear pump.
Large agitator, shears, presses, centrifuges, rotating supports, heavy capsizing and cranes, grinders, stone sanding machines, tipping machines, drilling machines, punching machines, convex axial presses, folding machines, machine tool turntables, barrel turning devices, oscillating devices, crushers
