Carry materials by hand → clamp the materials oven move along to forming area → heating → oven move back to heating area →lower-mold up → forming globularity by air pressure (pre-blown) → vacuum (With plug assistant) → cooling → automatic degassing →mold ejecting → lower mold down→ take out the finished product by hand.
Technical specification
Max. forming area | 2000*2000mm |
Max. height of mold | 900mm |
Max material thickness | 10mm |
Production speed | 5-30 Cycles/h |
Power of oven | Approx. 93.6kw |
Power of vacuum pump motor | 3kw |
Vacuum pump capacity | 100m3/h |
Overall dimension | 3400*4300*2800mm |
Machine weight | 9000kg |
