Features
With four air cylinders to ensure printing pressure even, and clear printing.
Fast adjusting for frame device height.
Ink blade and scrapper locking pressure can be adjust freely.
Printing itinerary and frame locking size can be adjust speedily.
Specification
Model | WPKB-80120 |
Max. printing dimension | 800 x1200mm |
Max. dimension of the frame | 1150 x1400mm |
Dimensions of the workbench | 1000 x 1300mm |
Printing to thickness | ~25mm |
Height of instant off-network | 0 - 20mm |
Printing speed | 900pcs/h |
Weight（Kg） | 900kg |
Overall dimensions（mm） | 1900x 1400x1400mm |
Printing motor | 1.1Kw |
Printing shaft | 1.1Kw |
Wind machine | 1.5Kw |
Power | 3.7Kw |
