Major Function
Hob cutting film + Single group film applicator
Servo motor paper feeding
Servo motor film feeding
Paper receiving stepper with batch counting
Paper vacuum adsorption transport
Double sheet / empty sheet gluing rising automatically
Paper length L ＜ 260mm  double sheet mode
Follow lable of film printing surface(optional)
Film with punching holes (optional)

Tissue box film middle cut (optional)

Specifications

G-650 Max. Paper Size	W650xL550mm
Paper gram above	Kraft Paper：150-1200g/㎡ White Cardboard：230-1200g/㎡ Corrugated Paper：≤3mm
Mini. Film	W30xL50mm
Max. Film Unwinding Diameter	400mm±2mm
Maximum Speed	15000pcs/h
Servo Motor	Driving part：Paper feeding department 1 set ，film delivery department 1 set
Stepping Motor	Driving Parts： Automatic paper receiving 1 set
Overall Weight	1720kg
